Product and packaging similar. Subject to modifications and errors.
Basic (Standard)
TV wall mount TILT (XXL)
50 to 100 inch (127–254 cm), max. 75 kg
Your TV deserves better than that dusty lowboard from 2005: Update your room design and mount your TV securely on the wall to save space. Up to 15° of continuous tilt angle ensures the right position without glare or reflections. Special feature: The click-in system allows you to securely lock your TV onto the wall plate. With the hand straps you can easily detach the television at any time, e.g. to connect other cables.
- Extra strong and flexible: The TV mount impresses with a load capacity of up to 75 kg, tilt function and 85 mm wall clearance – perfect for particularly large televisions
- Automatic Click-in & Easy Release: Hang the television on the wall mount and press to lock it securely into place. To open the click-in system, pull on the loops – and the television can be easily removed
- The tilt angle can be adjusted continuously between +5 and -10° to reduce glare and reflections on the screen
- The integrated spirit level ensures precise alignment and easy installation of the television
- Flexibly adjustable to the left or right on the wall rail for optimal alignment of the screen mount even after installation
- The TV wall mount is suitable for most curved and flat-screen TVs from popular brands, such as Samsung (QLED and LED), Sony, Philips and LG, as well as many sizes, such as 50'', 55'', 58'', 65'', 75'', 85'' and 100''
- The TV mount is compatible with the VESA standard 900x600 mm and all smaller VESA dimensions
Technical specifications
Performance
| Bracket type | TV Tilt |
| screen size | XL (109-254cm / 43-100") |
| maximum load | 75 kg |
| min. Wall distance | 85 |
| inclination and tilting ranges | +5° ~ -10° |
| max. Mouting Hole (VESA) | 900x600 |
| VESA (FDMI) | 75 x 75 mm, 100 x 100 mm, 100 x 150 mm, 150 x 100 mm, 100 x 200 mm, 200 x 100 mm, 150 x 150 mm, 200 x 200 mm, 200 x 300 mm, 300 x 200 mm, 200 x 400 mm, 400 x 200 mm, 300 x 300 mm, 300 x 400 mm, 400 x 300 mm, 600 x 200 mm, 400 x 400 mm, 600 x 300 mm, 600 x 400 mm, 600 x 600 mm, 800 x 400 mm, 800 x 600 mm, 900 x 600 mm |
General
| Color | black |
| Material | steel (powder-coated) |
| Packaging type | Retail Box |
Dimensions / Weight
| Consumption Unit | 1 pc. in cardboard box |
| Width | 938 mm |
| Height | 625 mm |
| depth | 85 mm |
| Weight | 3300 g |
Scope of delivery
| Assembly Material | dowel, screws |
warranty
| Warranty | 30 years |
Downloads
Product data sheet pdf
zł105.99 RRP
Packing units:
1 / 5
